Affichage de données d'un fichier.txt

chemin = "TempsFonction.txt"
Nb_Element = []
TriBulle = {"Temps": [], "NBOE": []}
TriRapide = {"Temps": [], "NBOE": []}
TriDenombrement = {"Temps": [], "NBOE": []}

Chaine = "QuelqueChose"
with open(chemin, "r") as Fichier:
    Fichier.readlines(1)

    while(True):
        Chaine = Fichier.readlines(1)

        if(len(Chaine) == 0):
            break
#La dernière ligne du fichier est vide.

        Chaine = Chaine[0].replace(": ","; ")
        Chaine = Chaine.replace("\n","")
        Liste = Chaine.split("; ")

        Nb_Element.append(Liste[0])

        TriBulle["Temps"].append(Liste[1])
        TriBulle["NBOE"].append(Liste[2])

        TriRapide["Temps"].append(Liste[3])
        TriRapide["NBOE"].append(Liste[4])

        TriDenombrement["Temps"].append(Liste[5])
        TriDenombrement["NBOE"].append(Liste[6])

import matplotlib.pyplot as plt

# Ajouter les données aux tableaux pour les abscisses et les ordonnées
x = Nb_Element
y = TriBulle["Temps"]

# Tracer le graphique
plt.plot(x, y)

# Ajouter les étiquettes pour les axes
plt.xlabel("Nb_Element")
plt.ylabel("TempsTri")

# Ajouter un titre pour le graphique
plt.title("Tri BubbleSort")

# Afficher le graphique
plt.show()

/usr/lib/python3/dist-packages/pandas/util/testing.py:28: FutureWarning: In the future `np.bool` will be defined as the corresponding NumPy scalar.

  import pandas._libs.testing as _testing
Traceback (most recent call last):
  File "/home/etudiant/dj222837/PycharmProjects/pythonProject/AfficherDonnées.py", line 41, in <module>
    plt.plot(x, y)
  File "/home/etudiant/dj222837/.local/lib/python3.8/site-packages/matplotlib/pyplot.py", line 2748, in plot
    return gca().plot(
  File "/home/etudiant/dj222837/.local/lib/python3.8/site-packages/matplotlib/pyplot.py", line 2245, in gca
    return gcf().gca()
  File "/home/etudiant/dj222837/.local/lib/python3.8/site-packages/matplotlib/pyplot.py", line 842, in gcf
    return figure()
  File "/home/etudiant/dj222837/.local/lib/python3.8/site-packages/matplotlib/_api/deprecation.py", line 454, in wrapper
    return func(*args, **kwargs)
  File "/home/etudiant/dj222837/.local/lib/python3.8/site-packages/matplotlib/pyplot.py", line 783, in figure
    manager = new_figure_manager(
  File "/home/etudiant/dj222837/.local/lib/python3.8/site-packages/matplotlib/pyplot.py", line 358, in new_figure_manager
    _warn_if_gui_out_of_main_thread()
  File "/home/etudiant/dj222837/.local/lib/python3.8/site-packages/matplotlib/pyplot.py", line 336, in _warn_if_gui_out_of_main_thread
    if _get_required_interactive_framework(_get_backend_mod()):
  File "/home/etudiant/dj222837/.local/lib/python3.8/site-packages/matplotlib/pyplot.py", line 207, in _get_backend_mod
    switch_backend(dict.__getitem__(rcParams, "backend"))
  File "/home/etudiant/dj222837/.local/lib/python3.8/site-packages/matplotlib/pyplot.py", line 265, in switch_backend
    backend_mod = importlib.import_module(
  File "/usr/lib/python3.8/importlib/__init__.py", line 127, in import_module
    return _bootstrap._gcd_import(name[level:], package, level)
  File "<frozen importlib._bootstrap>", line 1014, in _gcd_import
  File "<frozen importlib._bootstrap>", line 991, in _find_and_load
  File "<frozen importlib._bootstrap>", line 975, in _find_and_load_unlocked
  File "<frozen importlib._bootstrap>", line 671, in _load_unlocked
  File "<frozen importlib._bootstrap_external>", line 848, in exec_module
  File "<frozen importlib._bootstrap>", line 219, in _call_with_frames_removed
  File "/snap/pycharm-professional/319/plugins/python/helpers/pycharm_matplotlib_backend/backend_interagg.py", line 11, in <module>
    from datalore.display import debug, display, SHOW_DEBUG_INFO
  File "/snap/pycharm-professional/319/plugins/python/helpers/pycharm_display/datalore/display/__init__.py", line 1, in <module>
    from .display_ import *
  File "/snap/pycharm-professional/319/plugins/python/helpers/pycharm_display/datalore/display/display_.py", line 7, in <module>
    from .supported_data_type import _standardize_value
  File "/snap/pycharm-professional/319/plugins/python/helpers/pycharm_display/datalore/display/supported_data_type.py", line 11, in <module>
    import pandas
  File "/usr/lib/python3/dist-packages/pandas/__init__.py", line 182, in <module>
    import pandas.testing
  File "/usr/lib/python3/dist-packages/pandas/testing.py", line 7, in <module>
    from pandas.util.testing import (
  File "/usr/lib/python3/dist-packages/pandas/util/testing.py", line 28, in <module>
    import pandas._libs.testing as _testing
  File "pandas/_libs/testing.pyx", line 10, in init pandas._libs.testing
  File "/home/etudiant/dj222837/.local/lib/python3.8/site-packages/numpy/__init__.py", line 305, in __getattr__
    raise AttributeError(__former_attrs__[attr])
AttributeError: module 'numpy' has no attribute 'bool'.
`np.bool` was a deprecated alias for the builtin `bool`. To avoid this error in existing code, use `bool` by itself. Doing this will not modify any behavior and is safe. If you specifically wanted the numpy scalar type, use `np.bool_` here.
The aliases was originally deprecated in NumPy 1.20; for more details and guidance see the original release note at:
    https://numpy.org/devdocs/release/1.20.0-notes.html#deprecations

import pandas as pd
import matplotlib.pyplot as plt

df = pd.read_csv("TempsFonction.txt", sep=";")
data = {}
for column in df.columns:
    # on coupe le header de colonne séparé par : et on ne prend pas l'espace juste après
    alg = column.split(":")[1:][0][1:]
    data[alg] = {"NB_Element": df[column].apply(lambda elem: elem.split(":")[0]).values,
                 "TempsTri": df[column].apply(lambda elem: elem.split(":")[1]).values}

for key,values in data.items():
    plt.plot(values['NB_Element'], values['TempsTri'], label=key)

plt.legend()
plt.show()

# TempsFonction.txt
Nb_Element: TempsTriBulle; NB_OperationTB: TempsTriRapide
0: 0;0: 0
1: 1; 1: 1
2: 2; 2: 4
3: 3; 3: 9
4: 4; 4: 16
5: 5; 5: 25
6: 6; 6: 36
7: 7; 7: 49
